Four-sided trolley with vertical tubes
| Colour: | RAL 7016 |
|---|---|
| Dimensions - width x depth x height (mm): | 2275 x 900 x 1105 |
| Load capacity (kg): | 500 |
| Loading Surface - width x depth (mm): | 2005 x 810 |
| Weight (kg): | 104,5 |
| Wheelset: | Thermoplastisches Gummi |
| Wheel width (mm): | 40 |
| Wheel Ø (mm): | 200 |
Pick your accessory
from €0.00*
€0.00*
GTIN/EAN:
4035694076723
Product number:
sw-2014/AG
Product information "Four-sided trolley with vertical tubes"
Modular system
Welded steel construction
With waterproof bonded plywood base, surface finish screen printed, anti-slip
Permanent surface protection
Impact- and scratch-resistant
End and side walls with vertical tubes
End walls with horizonal push bar
Hight of end and side walls: 800 mm
Side walls removable
Grey non-marking thermoplastic rubber tyres on plastic wheel rim with precision deepgroove ball bearings
Thread guard and foot guard
2 swivel castors with brakes and 2 fixed castors
1.200 kg carrying capacity: Elastic solid-rubber tyres on cast aluminium wheel rim with precision deepgroove ball bearings with foot guard
2 swivel castors with central foot brake EasySTOP and 2 fixed castors (EasySTOP can be operated on one longitudinal and narrow side).
Welded steel construction
With waterproof bonded plywood base, surface finish screen printed, anti-slip
Permanent surface protection
Impact- and scratch-resistant
End and side walls with vertical tubes
End walls with horizonal push bar
Hight of end and side walls: 800 mm
Side walls removable
Grey non-marking thermoplastic rubber tyres on plastic wheel rim with precision deepgroove ball bearings
Thread guard and foot guard
2 swivel castors with brakes and 2 fixed castors
1.200 kg carrying capacity: Elastic solid-rubber tyres on cast aluminium wheel rim with precision deepgroove ball bearings with foot guard
2 swivel castors with central foot brake EasySTOP and 2 fixed castors (EasySTOP can be operated on one longitudinal and narrow side).
| Colour: | RAL 7016 |
|---|---|
| Dimensions - width x depth x height (mm): | 2275 x 900 x 1105 |
| Load capacity (kg): | 500 |
| Loading Surface - width x depth (mm): | 2005 x 810 |
| Weight (kg): | 104,5 |
| Wheelset: | Thermoplastisches Gummi |
| Wheel width (mm): | 40 |
| Wheel Ø (mm): | 200 |
